Water Pressure Sensors and Transmitters
The industry application of MicroSensor water pressure sensors involves hydrology and water conservancy, environmental monitoring, and more. The accurate measurement aims at depth, pressure, and flow rates. Various application sites include static pressure measuring of the pipelines, vessels, tanks, etc. The pressure transducer is available to measure the groundwater depth of boreholes and agriculture irrigations. Micro Sensor experts offer professional technical advice and support for selecting and installing water pressure transmitters.
ATEX Pressure Transmitter
[MPM489]
-1bar...0mbar~100bar…1000bar
General / Flush Diaphragm
CE, RoHS, ATEX approved
DNV and ABS certifications for installation on the ship
Pressure Transmitter Suitable For General Industry
[M20]
Range: 0~250mbar to 0~250bar
Accuracy:±0.25%FS, ±0.5%FS
Output: 4mA~20mA DC, 0/1V~5/10V DC, 0.5V~4.5V DC
Digital Pressure Transmitter
[MPM3801A]
Range:0.07Bar~1000Bar
Accuracy: ± 0.25%FS
General use structure
Digital RS485 HART Pressure Transmitter
[MPM4730]
Range:-1bar...0~0.1bar…1000bar
Accuracy: ±0.15%FS (Typ.)
RS485/HART Protocol
DNV approved for ship use
Water Level Sensors
Generally, the water tank pressure sensors sense the amount of water in the containers or the change rate at that level as we can call water level sensors. Within the tanks or containers, the air above the water is compacted as the water level increases, exerting more pressure on the water tank sensor. The sensor signal is converted into a digital value thus the water amount or level can be measured.
Similar to tanks, the groundwater, and borehole levels can be measured with water level pressure sensors. MicroSensor offers a series of water pressure level sensors for water pressure measuring applications.
Submersible Level Transmitter
[MPM489W]
Φ26mm
0m~1m…200m H2O
Accuracy: ±0.25%FS, ±0.5%FS, ±1%FS
DNV approved for installation on all vessels
ATEX Certificated
Intelligent Level Transmitter
[MPM4700]
3.5, 7, 10, 20, 35, 70, 100, 200mH2O
Accuracy: ±0.1%FS (Typ.)
HART Protocol
DNV approved for ship use
Level Transmitter for Low Level
[MPM436W]
Low Level Measurement
Range: 0-10mH2O
Accuracy: ±0.5%FS(Min.)
How Does a Water Pressure Sensor Work?
A water pressure transmitter can measure the pressure or level of the water. Application scenarios include but are not limited to water tanks, water pipelines, and water containers.
Water Pressure (in pipes) → Direct reading (bar/psi). Water pressure sensor measures the force (psi/bar) exerted by water against the sensor’s diaphragm. The sensing diaphragm converts pressure to a current signal through the circuit to fulfill the whole measurement.
Water Level (in tanks/containers) → Uses hydrostatic pressure (P = ρgh) to calculate water height.
Requirements of Water Pressure Sensor for Different Water Applications
| Applications | Requirements |
| Water Distribution Networks | - Smart communication protocols (MODBUS, HART) - Anti-corrosion materials for long-term deployment - Data logging for flow and pressure analysis |
| Pump Control and Monitoring | - High response time for pump automation - Overpressure protection systems - Robust and Shock-Resistant Design |
| Water Treatment Plants | - Compatibility with harsh chemicals and conditions - Wide pressure range for different process stages |
| Reservoir & Tank Level Measurement | - Hydrostatic measurement principle - Mounted or submersible options |
Features of Water Pressure Transmitter for Pipelines/Tanks
| Applications | Specific Features | |
| Pipelines | Clean Water Pipelines | - Gauge pressure (stainless steel diaphragm), 4-20mA - Threaded/flanged connections |
| Wastewater/Sludge Pipelines | - Flush diaphragm, clog-resistant - Hastelloy material | |
| High-Pressure Water Mains | - High-accuracy & stability - Wide pressure range | |
| Tanks | Open Tanks | - Submersible hydrostatic, IP68 - Side-mounted, gauge pressure |
| Closed/Pressurized Tanks | - Top/side-mounted, absolute pressure - Explosion-proof | |
Micro Sensor Offers Water Monitoring Solutions
Water is central to both residential comfort and industrial productivity. Proper water pressure management ensures that water flows adequately where and when needed for optimal system performance, benefiting conservation and sustainability beyond mere usage.
Whether in industrial, municipal, or residential water management, our pressure range of water pressure transducers covers the typical different applications, from 0mbar up to 1000bar. Featuring accuracy, durability, easy integration, and long-term performance, our water monitoring solution is indispensable, as it minimizes wastage and energy consumption and reduces operational costs. Contact our industrial expert for professional support or explore more details about the water & wastewater measurement solution.
