High-Stability Pressure Sensor
MPM281S
- · Long-term stability of ±0.1% FS/year
- · 0bar~0.2bar…35bar
Used For
Pressure Instruments Manufacturing, Pressure Calibrators, Gas and Liquid Pressure/Temperature Measurement
Leave a MessageMPM281S
Used For
Pressure Instruments Manufacturing, Pressure Calibrators, Gas and Liquid Pressure/Temperature Measurement
Leave a MessageManufactured on fully automated production lines, the MPM281S high-stability pressure sensor undergoes exacting inspection and testing to ensure high quality. Encased in a Ф19 mm 316L stainless steel housing, the sensor integrates a highly reliable piezoresistive silicon chip. It features advanced temperature and zero-offset compensation across a wide temperature range. Engineered to deliver superior accuracy and exceptional long-term stability, the pressure capsule is perfectly suited for pressure transmitters manufacturing, laboratory calibration instruments, as well as metrology-grade flowmeters and valve compensation systems.
Image:
Manufactured on fully automated production lines, the MPM281S high-stability pressure sensor undergoes exacting inspection and testing to ensure high quality. Encased in a Ф19 mm 316L stainless steel housing, the sensor integrates a highly reliable piezoresistive silicon chip. It features advanced temperature and zero-offset compensation across a wide temperature range. Engineered to deliver superior accuracy and exceptional long-term stability, the pressure capsule is perfectly suited for pressure transmitters manufacturing, laboratory calibration instruments, as well as metrology-grade flowmeters and valve compensation systems.
Read / Download our Datasheet in PDF
Download
Relate Solutions
-
River Monitoring
Monitor level and flow data within the river channel. Issue a warning when the water level is about to exceed the river warning line. Additionally, water quality sensor can be installed to report data such as pH value and turbidity to the relevant department's monitoring center when these values exceed normal levels. This monitors water quality, protects the river water environments, and provides data support for the supervision of illegal discharge and leakage.
more info... -
Bottle Washing Machine
Before beer bottles, medicine bottles, and condiment bottles are filled with liquid, they need to be cleaned first. The cleaning process is as follows: First, the bottles are filled with lye in the alkali tank to remove most of the stains; then, the bottles are back washed with high pressure using water of different temperatures to wash away the remaining impurities and lye. To ensure the stable operation of the bottle washing machine, the level of the alkali tank needs to be measured by hydrostatic pressure. In addition, the pressure of the alkali tank water inlet pipe and the nozzle pipe also needs to be measured.
more info... -
Remote Valve Control
To ensure the fuel supply of the main engine, the separated heavy oil is first pumped to the settling tank, where the oil is heated and separated in the heating coil, and then purified by the oil separator before entering the daily tank through high-level overflow. The daily tank is directly connected to the main engine, boiler or other equipment, and the oil can be heated and used at any time.
more info... -
Water Supply Pipe Network Pressure and Flow Monitoring
Monitoring the pressure, flow and other specifications of the entire pipe network by installing the monitoring device in water supply pipe network well contributes to scientifically scheduling water supply and ensuring the stable operation of the water supply system.
more info...
