Anti-corrosive Pressure Sensor
MPM280TH
- · Φ19mm
- · -1bar...0bar~1bar…700bar
- · Tantalum Diaphragm
Used For
Chemical Plants, Oil and Gas Refineries, Wastewater Treatment Plants
Leave a MessageMPM280TH
Used For
Chemical Plants, Oil and Gas Refineries, Wastewater Treatment Plants
Leave a MessageThe MPM280TH Anti-corrosive Pressure Sensor is integrated diffused silicon pressure sensor. It is a high-quality device designed for industries that require the measurement of corrosive media. It features a tantalum diaphragm and Hastelloy C276 housing, ensuring that the sensor can withstand harsh environmental conditions. This pressure sensor is available with a variety of mechanical and electrical configurations, both standard and customized, to accommodate a wide range of industrial applications.
Features
• Pressure range: 0bar ~ 1.0bar…700bar
• Gauge, Absolute and Sealed gauge
• Constant current or Constant voltage
power supply for option
• Φ19mm OEM pressure element
• Different metals with excellent corrosion
resistance for option
Specifications
• Pressure Range: 0bar ~ 1.0bar…700bar
• Type: Gauge, Absolute, Sealed Gauge
• Dia: Φ19mm OEM pressure element
• Power Supply: Constant current or Constant voltage for option
• Diaphragm: Titanium (MPM280Ti), Tantalum (MPM280TH, MPM280TS), Hastelloy C (MPM280HH)
• Housing: Titanium (MPM280Ti)
• Hastelloy C (MPM280TH, MPM280HH)
• Pressure leading tube: Stainless steel 316L
Image:
The MPM280TH Anti-corrosive Pressure Sensor is integrated diffused silicon pressure sensor. It is a high-quality device designed for industries that require the measurement of corrosive media. It features a tantalum diaphragm and Hastelloy C276 housing, ensuring that the sensor can withstand harsh environmental conditions. This pressure sensor is available with a variety of mechanical and electrical configurations, both standard and customized, to accommodate a wide range of industrial applications.
Features
• Pressure range: 0bar ~ 1.0bar…700bar
• Gauge, Absolute and Sealed gauge
• Constant current or Constant voltage
power supply for option
• Φ19mm OEM pressure element
• Different metals with excellent corrosion
resistance for option
Specifications
• Pressure Range: 0bar ~ 1.0bar…700bar
• Type: Gauge, Absolute, Sealed Gauge
• Dia: Φ19mm OEM pressure element
• Power Supply: Constant current or Constant voltage for option
• Diaphragm: Titanium (MPM280Ti), Tantalum (MPM280TH, MPM280TS), Hastelloy C (MPM280HH)
• Housing: Titanium (MPM280Ti)
• Hastelloy C (MPM280TH, MPM280HH)
• Pressure leading tube: Stainless steel 316L
