Small Size Pressure Sensors

Pressure sensors with a small size can be used to pressure measuring applications that have strict requirements for dimensions. The pressure sensor diameter ranges from Φ12.6mm to Φ19mm and the height can be as small as 6.5mm. The compact size pressure sensor is widely used for pressure measurement of media which is compatible with stainless steel and Viton, especially the working site with limit installation space.
Pressure Range
≤1bar ( 1 )
≤35bar ( 3 )
>35bar ( 2 )
Power Supply
≤2.0mA DC ( 3 )
10V DC (100±2 mV) ( 0 )
3.0V~5.5V DC ( 0 )
Diameter
19mm ( 0 )
15mm ( 1 )
≤12.6mm ( 2 )
Height
26mm ( 0 )
18mm ( 0 )
15mm ( 0 )
13.5mm ( 0 )
12mm ( 1 )
11.5mm ( 0 )
10.5mm ( 2 )
6.5mm ( 0 )
Temperature Compensation
0~50℃ ( 0 )
0~70℃ ( 1 )
-10~80℃ ( 2 )
Other Options
Sanitary ( 0 )
Flush Diaphragm ( 0 )
Anti-Corrosive ( 0 )
With Temp. ( 0 )
High Pressure Range Pressure Sensor

High Pressure Range Pressure Sensor

MPM283II

Φ12.6x10.5mm
0bar~1bar…1000bar
-10~80℃ Compensated
Oil-filled Pressure Sensor

Oil-filled Pressure Sensor

MPM285

Φ15×10.5mm
0bar~1bar...35bar
0~70℃ Compensated Temp.
High Pressure Range Pressure Sensor

High Pressure Range Pressure Sensor

MPM283I

Φ16.8x12mm
0bar~2bar…1000bar
-10~80℃ Compensated

Small Size Pressure Sensors Applications


Small size pressure sensors apply to pressure monitoring where limited space or critical size is required.


• Industrial Automation

Small-size pressure sensors are more suitable for liquid and gas pipeline systems with limited space. It can be integrated with automation control systems to achieve process control and equipment optimization.


• Environmental Monitoring

Small-format pressure sensors help measure air pressure, fluid level, and fluid pressure, providing important data on environmental conditions.


Micro Sensor's small and compact customized sensors adapt to space constraints applications. Small-size products are also suitable for pressure measurement of media compatible with stainless steel and fluoro rubber.
